GrafX™- Thermal Management Technology for Li-ion Batteries

CaloryTech designs, manufactures and supplies an innovative thermal management system for Lithium-ion batteries called GrafX™.

GrafX™ protects the battery packs from hot ambient temperature, reduces thermal runaway risk and maintains an optimal temperature for longer cycle and calendar life. TheGrafX™is designed to be the first of its kind plug-and-play, portable thermal management system that can be easily integrated into any Lithium-ion battery system especially for Range Extender or swappable battery packs where liquid or air-cooling system cannot be incorporated. In addition to thermal management,GrafX™ also functions as a cell holder, thus eliminates the need for plastic cell holders.

CaloryTech designs, manufactures and supplies an innovative thermal management system for Lithium-ion batteries called GrafX™.

GrafX™ protects the battery packs from hot ambient temperature, reduces thermal runaway risk and maintains an optimal temperature for longer cycle and calendar life. TheGrafX™is designed to be the first of its kind plug-and-play, portable thermal management system that can be easily integrated into any Lithium-ion battery system especially for Range Extender or swappable battery packs where liquid or air-cooling system cannot be incorporated. In addition to thermal management,GrafX™ also functions as a cell holder, thus eliminates the need for plastic cell holders.

Lithium-ion Battery Packs with GrafX™

CaloryTech specializes in crafting Lithium-ion battery packs featuring its cutting-edge GrafX™ technology. These battery packs find applications in a wide array of sectors, including electric 2W/3W/4W vehicles, solar charging stations, drones, and stationary uses like telecom towers and UPS systems.

  • Electric Vehicles: CaloryTech’s Lithium-ion battery packs are tailor-made for electric two-wheelers (2W), three-wheelers (3W), and four-wheelers (4W). These high-performance battery solutions power sustainable transportation, offering longer ranges and faster charging times.
  • Solar Charging Stations: The company’s battery packs play a pivotal role in solar charging stations. They store renewable energy efficiently, ensuring continuous power supply even during cloudy days or at night, promoting clean energy adoption.
  • Drones: CaloryTech’s GrafX™ integrated battery packs are crucial for drones, enabling extended flight durations and robust performance. This technology is instrumental in various industries, from agriculture to surveillance.
  • Telecom Towers: CaloryTech addresses the critical need for reliable power at telecom towers. Their battery packs ensure uninterrupted connectivity in remote areas or during power outages, enhancing communication networks.
  • UPS Systems: In the realm of Uninterruptible Power Supply (UPS), CaloryTech’s battery packs safeguard critical operations in various sectors, such as data centers, healthcare, and manufacturing, ensuring seamless power backup solutions.

CaloryTech’s commitment to innovation and sustainable energy solutions positions them as a key player in the field of Lithium-ion battery technology. Their GrafX™ integration not only enhances the performance of these batteries but also contributes significantly to reducing the carbon footprint across diverse sectors, aligning with the global shift towards clean and efficient energy solutions.

Lithium-ion Battery Packs for Telecom Towers, Solar Charging Stations and e-Autorickshaws

System Sizing can go up to 20 Modules connected in Parallel BMS Features include :

  • CAN bus enabled
  • Short circuit protection
  • Overcharge Protection
  • Cell Balancing
  • SOC Readings
  • Overcurrent cutoff
  • High temperature cutoff

Lithium-ion Battery Packs for Automotive Applications

CaloryTech provides customized battery packs with GrafX™ for automotive applications like e-bikes, e-scooters, electric cars, cargo vans that are highly modular and scalable.



Specifications 1.6 kWh Modules
ALFA 51-1.6		 6.4 kWh Modules
ALFA 51-6.4
Nominal Voltage 51V 51V
Nominal Capacity 31.4 Ah 125.4 Ah
Nominal Energy 1.6 kWh 6.4 kWh
Dimensions (approx.) 12″ x 10″ x 4” 24″ x 12″ x 6”
Weight (approx.) 12 Kg 46 Kg
Temperature Range* Discharge (Charge) -20 to 60°C
(0 to 40°C)		 -20 to 60°C
(0 to 40°C)
Maximum Discharge Continuous Peak 32 A

64 A

 64 A

128 A

GrafX™

CaloryTech batteries are integrated with GrafX™ which absorbs heat rapidly, ensuring uniform battery pack temperature. The result is best-in-class safety with extended cycle life.

Integrated BMS Features

  • Cell Balancing
  • High Temperature Cutoff
  • Overcurrent Cutoff
  • Overcharge Protection
  • Overdischarge Protection
  • Short Circuit Protection

System Benefits

  • Perfect for hot environments
  • Ideal for use in remote locations
  • Long-lasting and durable
  • 25% the weight of equivalent lead-acid batteries
  • Maintenance-free
  • Protection against thermal runaway propagation
